From radar charts to curve fitting and back

What started as an investigation into a few radar area charts and whether they were doing any real analytical work turned into a data adventure with a few new insights for me. The original view is from a Nature article, Designing allosteric modulators to change GPCR G protein subtype selectivity. I have no understanding of the content, but I wanted to try and determine the utility of these radar area charts from a data visualization perspective. At first scan, all I could see was Pac-Man, Germany, and Excalibur.

Radar charts and heatmaps summarizing relative efficacy and log EC₅₀ across sensors for three compounds.
—
The figure is arranged in three groups corresponding to compounds NT, PD149163, and SBI-553. For each compound, a filled radar chart displays relative efficacy across sensors arranged radially, with a scale from 0 to 1.0. To the right of each radar chart, a vertical heatmap shows log EC₅₀ values in molar units for the same sensors, with color intensity indicating magnitude; some entries are blank or marked as missing. NT displays a nearly circular radar shape with values close to 1.0 across most sensors, while PD149163 and SBI-553 show increasingly irregular shapes with more zero or near-zero values. Relative efficacy is encoded only in the radar charts, while log EC₅₀ is encoded only in the heatmaps.

Getting the data

This article comes with several data files, and it even has a Source Data link paired with this figure, which is usually the best possible scenario. However, I looked through that file and many of the supplementary data files and couldn’t find anything that reasonably matched the quantities represented in the radar charts. Finally, upon reading the figure caption a little closer, I realized the linked data was for Figure 1b, and that the radar charts in 1c used data derived from the fitted curves in 1b.

Small-multiple dose–response plots showing transducer activation versus compound concentration across sensors.
—
The figure consists of a grid of small-multiple panels, one for each sensor (including Gq, G11, G15, Gi subtypes, Go subtypes, Gz, Gg, G12, G13, GsS, β-arrestin 1, and β-arrestin 2). Each panel plots transducer activation (y-axis, labeled “± Δ Net BRET,” ranging from 0 to about 0.6) against log compound concentration in molar units (x-axis, from approximately −12 to −4). Four compounds are shown using distinct colors and markers: NT (blue), PD149163 (green), SBI-553 (magenta), and SR142948A (orange). Points represent measured responses at each concentration, with smooth sigmoidal curves indicating fitted dose–response relationships. NT generally shows earlier and stronger activation across many sensors, PD149163 activates at higher concentrations, SBI-553 shows weaker or delayed responses in several panels, and SR142948A remains near zero across most sensors.

So now I have a subgoal to recreate Figure 1b from the data. The provided data was in an Excel file containing 15 sheets and each sheet had 4 subtables arranged in a 2-by-2 layout.

Screenshot of a semi-structured Excel worksheet containing multiple dose–response subtables.
—
The image shows a spreadsheet worksheet containing several rectangular subtables arranged in a grid. Each subtable is labeled by compound and sensor, with headers such as “Log [NT], M” or “Log [PD149163], M.” Within each subtable, the first column lists compound concentrations on a logarithmic scale, and subsequent columns contain numeric response values labeled by date. Dates repeat across columns, indicating measurements taken on different experimental days. The subtables vary in size and are separated by blank rows and columns, forming a regular but non-tidy layout that requires custom parsing to extract into a structured dataset.

Since the subtables were not the same size from sheet to sheet, I couldn’t think of a way to extract the data into a tidy representation using standard data import/reshape steps. Still, the structure is fairly regular, so I started to write a script to identify the subtables and extract the data.

But before I got too far, I had a better idea: see if ChatGPT could help me extract the data. And it could! After I described the structure I had already deduced, it almost succeeded on the first try. It just missed the 2×2 layout, but it handled that after a reminder. I then had it make a couple more refinements to normalize the date fields. Nicely, it provided the original Excel row/column coordinates, so I could trace each value if needed. I only spot-checked a few values since the graphs would be my real quality check.

Making graphs

Here’s a quick mock-up of Figure 1b using a constrained p-spline in lieu of a fitted logistic curve as a quick visual stand-in before worrying about the exact functional form. The other noticeable difference is that my version shows all the data values while the original only shows one point per X per overlay (the mean).

Recreated dose–response panels using constrained spline fits and showing all individual data points.
—
The figure reproduces the small-multiple layout of the original dose–response plots, with one panel per sensor plotting activation versus compound concentration on a logarithmic x-axis. All individual measurements are shown as points for four compounds—NT (blue), PD149163 (green), SBI-553 (magenta), and SR142948A (orange)—rather than summary points. Smooth curves are constrained spline fits that are forced to be non-descending with a minimum of zero. Overall response patterns resemble those in the original figure, while the inclusion of all points reveals variability and clustering not visible when only means are shown.

Showing all points makes within-X variability visible, and enables observation of other patterns in the data. For example, I noticed the blue dots in the center panel (sensor protein GoA) look separated into two clumps for each X, with some relatively far above the fitted curve. Zooming into that panel and selecting those points shows they’re all tagged with the same day value.

Selected points in the GoA dose–response plot linked to their corresponding rows in the data table.
—
The image shows the GoA sensor panel with activation plotted against compound concentration and a smooth fitted curve. Several points at higher concentrations lie above the curve and are selected, appearing darker than surrounding points. To the right, a tabular view of the underlying data shows corresponding rows highlighted. The highlighted rows share the same compound and repeated day values, indicating that the clustered points originate from measurements taken on the same experimental day rather than independent replicates.

Hmmm, I don’t know if that’s anything to worry about, but it does make me realize the responses have some degree of serial correlation. Checking the paper’s Methods section confirms that each sequence of concentration readings was taken from the same sample at different points in time as the concentration increased. That might suggest some sort of fixed effects model, and maybe that’s part of the lengthy explanation in the supplementary material.

Logistic Fits

The paper’s main text mentions a three-parameter sigmoidal curve fit with unconstrained lower and upper asymptotes, which I didn’t understand at first because I was thinking in terms of logistic curves which would need four parameters in that situation. Later I noticed the details in the supplementary materials and realized they used a different form (Hill sigmoidal function) with many additional knobs beyond that. Furthermore, it sounds like they did fit four parameters for the basic Hill formulation but one was shared by all curves. They also made a few special modifications for cases where the fit was poor and reverted to linear models or clipped parameters.

Before knowing all that, I proceeded with three-parameter logistic fits (fixing the lower asymptote to 0), which comes close enough to the original chart for my purposes.

Dose–response panels refit with three-parameter logistic curves and mean ± standard error.
—
The figure shows a grid of dose–response panels with activation plotted against compound concentration on a logarithmic scale. Points represent mean activation at each concentration with vertical error bars indicating one standard error of the mean. Smooth curves show fitted three-parameter logistic models with the lower asymptote fixed at zero. In several panels, particularly for SBI-553, the fitted curves rise very steeply or extrapolate beyond the observed data range, indicating unstable fits when the data do not clearly define a full sigmoidal shape.

My curves extend beyond the data values, which does help see which curves never flatten out, and the poor fits like GsS are too close to the origin to discern much anyway.

I don’t know enough about the science to understand why they wouldn’t fix the lower asymptote at zero. Perhaps they wanted to minimize assumptions that would look like data tinkering.

I did have a hiccup for one of my logistic fits. My initial three-parameter logistic fit for the pink curve in G13 looked like:

Three-parameter logistic fit with an implausible flat plateau far from the data range.
—
The plot shows activation versus log₁₀ concentration for a single compound and sensor. Observed data points cluster at higher concentrations, while the fitted three-parameter logistic curve rises sharply at extremely low concentrations and then remains nearly flat across the region where data are observed. The curve’s inflection and plateau occur far outside the data-supported range, producing a fit that does not track the observed response pattern and illustrating a structural failure of the model under these constraints.

I thought I had found a bug in JMP (the tool I help develop), but ChatGPT assures me that this is a well-known failure that can happen when the data never reaches a clear inflection point (appears exponential), calling it a “structural identifiability / leverage problem”. My simple fix was to pre-summarize the data before fitting which stabilizes the fit but obviously discards some information.. A better fix would be to use the Hill sigmoidal function (which JMP calls Logistic 4P Hill) like the paper does since it isn’t prone to this failure. However, there’s no convenient three-parameter version and what I have seems good enough to move to the radar chart step in the journey.

Radar data

Getting back to the radar charts, here is a bigger view of the original.

Enlarged excerpt of the original radar and heatmap summary for NT and PD149163.
—
The figure shows a subset of the original radar-and-heatmap summary, displaying only NT and PD149163 at a larger scale. For each compound, a filled radar chart shows relative efficacy across sensors arranged radially, and a vertical heatmap shows log EC₅₀ values for the same sensors. NT exhibits a nearly uniform radar shape with values close to 1.0, while PD149163 shows a more uneven profile. The encodings match the original figure but are enlarged to aid visual inspection.

Oddly, for each compound (NT and PD149163) there are two variables shown, relative efficacy and log(EC50), but one variable is shown with a radar chart, and one is shown with a heatmap. Not sure why they couldn’t use a heatmap for both (and with common color scales even). I guess they can’t use radars for both because of the negative values.

Efficacy seems to correspond to the top of each curve, with some clipping for those curves that don’t level off. Log(EC50) is the X value of the inflection point of the fitted curve. Relative efficacy is the efficacy divided by the corresponding efficacy for compound NT. Which means the NT relative efficacy values all 1.0(!), except when 0, making the radar chart pretty vacuous.

JMP is intentionally not so great at round charts in general and doesn’t have a radar area chart built in. The closest I could easily get is these coxcomb charts.

Coxcomb (polar bar) charts showing relative efficacy by sensor for each compound.
—
The figure contains four coxcomb charts, one per compound, with sensors arranged radially. Each sensor is represented by an independent wedge of equal angular width, and wedge length encodes relative efficacy. Unlike filled radar charts, wedges do not connect to neighboring sensors. NT forms an almost complete circle of similar-length wedges, PD149163 shows greater variation, SBI-553 displays a sparse pattern with several isolated wedges, and SR142948A shows only two non-zero wedges, making sparsity explicit.

I do prefer them to the filled radar charts since each wedge stands on its own and doesn’t rely on a connection with its neighbor. Pure speculation, but I wonder if that’s why they didn’t show the radar chart for the last compound in the paper. With no non-zero neighboring values the two non-zero sensors would have no area to fill.

Here’s what heatmaps look like for relative efficacy. There is still the pointless all-1.0 columns for NT (I removed the empty GsL).

Heatmap showing relative efficacy by sensor and compound.
—
The heatmap displays sensors as rows and compounds as columns, with cell color encoding relative efficacy on a light-to-dark blue scale. The NT column is uniformly dark due to normalization, indicating values near 1.0 across sensors. PD149163 shows generally high but variable values, SBI-553 shows lower values for many sensors, and SR142948A is near zero across most sensors. The heatmap allows direct comparison across compounds using a common scale and makes zero values explicit.

Keeping with the filled area theme of the original, here’s a non-circular version of that.

Paired linear area charts comparing absolute and relative efficacy across sensors.
—
The figure shows two side-by-side horizontal area charts with sensors listed vertically. The left panel displays absolute efficacy, and the right panel displays relative efficacy. Four semi-transparent filled shapes represent the compounds NT, PD149163, SBI-553, and SR142948A. In the absolute-efficacy panel, NT and PD149163 show larger areas across many sensors, while SR142948A remains near zero. In the relative-efficacy panel, NT forms a near-vertical boundary at approximately 1.0 due to normalization, while the other compounds vary more substantially. The linear layout avoids radial geometry while preserving an area-based visual metaphor.

Two versions, actually: one without the normalization and one normalized relative to NT.

Learnings

I don’t have enough domain context to assess how these visualizations communicate an appropriate message, but the exploration process still yielded useful insights.

  • ChatGPT can extract tidy data from semi-structured Excel spreadsheets
  • Certain constrained nonlinear models can exhibit structural identifiability problems. For three-parameter logistic, the most common problem can be avoided by Hill versions of the formula.
  • Radar area charts will fail if a non-zero value is surrounded by zeros. (I imagine even near-zeros would be problematic.)
  • (not mentioned above) My trick of using Unicode superscript digits for scientific notation doesn’t work so well for fonts that have different vertical positions for those characters.
Close-up of logarithmic x-axis labels showing misaligned superscript exponents.
—
The image shows a close-up of a logarithmic x-axis labeled with powers of ten using Unicode superscript notation (for example 10⁻¹², 10⁻¹⁰, 10⁻⁸, 10⁻⁶, and 10⁻⁴). The superscript exponent characters are vertically misaligned across labels, with some exponents sitting higher or lower relative to the baseline. This makes the labels appear uneven despite correct numeric values, illustrating a typographic limitation of Unicode superscripts in certain fonts.
